Description
This is the standard table/special items can be specially ordered.
Basic Name : KOMOTECH Wear Resistant Overlay Plate (KOMOTECH PLATE)
| Plate Name | Hardness (HrC) | Temperature | Composition | |||||
| KP - 60 (HCC-0-3) | 58 - 62 | 350° | Hi-Cr Carbide (Main Product) | |||||
| KP - 62 | 61 - 63 | 550° | Special Complex Carbide | |||||
Sizes
Different steels, hardness, thickness, sizes and slides can be manufactured to user's order.
The standard table :
| Size Name | SUPER PLATE | Standard steel plate (mm) | ||||||
| Sizes (mm) | Square (m2) | |||||||
| 48 | 1100 x 2300 | 2.53 | 4' x 8' x (1219 x 2438) | |||||
| 50 | 1400 x 2900 | 4.06 | 5' x 10' (1524 x 3018) | |||||
| Will be different size made by costumer ordered | ||||||||
Thickness
Forward is base metal thickness & back is welding thickness
| Standard | Sub-standard | Sub-standard | ||||
| 5T + 3T | ||||||
| 6T + 4T | 6T + 5T | 6T + 6T | ||||
| 7T + 4T | 7T + 5T | 7T + 6T | ||||
| 8T + 5T | 8T + 6T | 8T + 8T | ||||
| 10T + 5T | 10T + 6T | 10T +10T | ||||
| 15T + 5T | 15T + 10T | 15T + 15T | ||||
| Will be different thickness made by costumer ordered | ||||||
Production Feature
Production features of super plate are
» Technical collaboration with KIMM (Korea Institute of Machinery Metals)
being authenticated laboratory secures public confidence.
» Production by AUTO MULTI-ARC WELDING system has uniformity and enables quick supply.
» Use base metal with mild steel though, different plate (Quenching plate like as HARDOX) can be used in special order.
Application
KOMOTECH PLATE is suitable for various industries :
CEMENT, STEEL PLANT, THERMO-ELECTRIC POWER PLANT, MINE, HEAVY EQUIPMENT, CERAMIC AND POWDER-MAID PLANT
Main application facilities are as follows :
» CEMENT KILNS
» CHUTES & LINERS
» FAN BLADES
» CRUSHER
» BLAST FURNACE BELLS BURDEN AREA
» TURNNION JOURNAL
» BLOWER
» MIXER
» DREDGE PUMP PARTS
» DUCT
» CYCLONES
» GREENAWALT CRUSHER
» HOPPER
» DAMPER
Application Method
